Shanghai Fire Inspection Fire Extinguisher Fire Extinguisher Repair…

When there is no inventory, the product is generally expected to be about 4-6 weeks, please order in advance!

Confirm the actual delivery period again before placing the order.

Please contact us at any time, thank you for your support and trust!IntersectionIntersection

Fire extinguisher impact testing machine, fire extinguisher filling equipment, professional supply and maintenance equipment manufacturer, MCJ-BThe fire extinguisher impact testing machine is a fire extinguisher testing and testing equipment independently developed by our company. It can complete the fire extinguisher impact and drop test in one go.conform toGB4351.1-2005 "Portable fire extinguisherNo.1 Part Structure and Performance》7.6.1, 7.6.2, 7.6.3 "Impact Test" requirements.
Fire extinguisher punch test machine mainDepend onIt consists of a test bench, a pillow steel block, a cylindrical flat-bottomed steel hammer, a sliding rod, an electromagnet, a specimen fixture, a calculator and an electrical automatic control system..Adjustable drop height: Fix the cylindrical flat-bottomed steel hammer on the wire rope, connect it to the sliding rod through the wire rope, and adjust the length of the wire rope to adjust the drop height.Reasonable design and simple operation: By controlling the button component and the relay to control the attraction and pulling of the electromagnet, the steel wire rope is controlled to complete the lowering impact of the cylindrical flat-bottomed steel hammer.Fire extinguisher impact testing machine, fire extinguisher filling equipment, professional supplier of maintenance equipment manufacturers. During impact, first pull out the drop pin on the sliding rod, then press the impact button and the electromagnet and the sliding rod will fall off. The cylindrical flat-bottomed steel hammer under the wire rope will quickly fall toward the axis of the fire extinguisher to complete an impact.Adjustable impact distance: Using branded electrical components, the electromagnet attracts the iron piece on the sliding rod to make the sliding rod reciprocate up and down to complete the impact performance test.It has the advantages of reliability, easy operation, measurement and flexible movement.

Technical Parameters:
1. Loading capacity: 50kg load
2. Impact distance: 300mm ~ 800mm
3. Impact steel hammer weight: 4kg±0.1kg
4. Power supply: AC220V 50HZ0.5kw

5. Weight: 100kg
6. Overall dimensions: length × width × height (unit mm) = 1000 × 500 × 1500, fire extinguisher impact testing machine, fire extinguisher filling equipment, professional supply and maintenance equipment manufacturer
